제품 상세 정보:
|
| p/n: | ATP050-12VDC | 냉각방식: | 플레이트 쿨 |
|---|---|---|---|
| 방사 방법: | 공군 | 주변 온도/습도: | -20 ~ 60 ° C |
| 냉각 용량: | 50W | 입력 전원: | 90W |
| 가열 용량: | 130W | 핫/콜드 사이드 팬 전류: | 0.4A / NA |
| TEM 공칭/시작 전류: | 8.0/9.0A | 공칭/최대 전압: | 12/15 VDC |
| 전체 차원: | 160mm x 122.4mm x 82mm | 무게: | 1.2kg |
| 생명 시간: | > = 70,000 시간 | 용인: | 10% |
| 강조하다: | 50W Peltier plate cooler for medical diagnostics,Thermoelectric cooler for industrial devices,Air to plate cooler for analytical instruments |
||
Adcol Peltier Thermal Cooler is your perfect choice for any Industrial, Commercial or Home application. Adcol is a well-known brand name from China and all of our Peltier Thermoelectric Modules have been certified with ISO9001 and CE.
The solid carton packaging ensures secure delivery and payment terms include T/T and Paypal. We guarantee a supply ability of 500pcs per month.
4. Performance Curve
5. Design drawing
6. Installation cut hole and Connector
